CG-AR Series

Best-in-class cutting pressure of 550 g and the speed improved to 105% of the conventional model

The cutting pressure can be selected from 10 g to 550 g, and three types of cutting are possible: normal cutting, complete cutting, and half cutting. The machine can cut a wide variety of materials, including PVC, fluorescent and reflective sheets, and rubber sheets.

Normal cutting / Full cutting / Half cutting

Optional products for cutting cardboard can be added to produce packages up to A3 size

CG-AR Series are now capable of producing high-quality cutouts from plain paper to cardboard with the use of optional products for cardboard cutting, such as a Sheet table, Cutting sheet, Blade for heavy paper and Creasing tool. Using this machine, you can produce paper crafts and packages.

Installation of a sheet table -> Setting cardboard attached to a cutting sheet on the table. -> Cutting is performed with a cardboard cutting blade, and the creasing-tool makes folding lines.

Examples of production

Paper craft / Package

Supporting for Windows plotter driver allows you to cut without the need for dedicated software

With use of familiar software such as Microsoft Word/Excel/PowerPoint, cutting is now as easy as outputting from a general office printer.

Supporting for Windows plotter driver allows you to cut without the need for dedicated software

"ID Cut function" provided for efficient Print & Cut

"ID cut" is a function for automatically cutting data included in an ID simply by scanning the ID register marks output by Mimaki's optionally available printer*. Data transmission from the PC is completed with one-time operation, which drastically saves labor for print & cut and enhances work efficiency.
* Compatible with the JV330 Series, JV300Plus Series and the JV/UJV100 Series

"ID Cut function" provided for efficient Print & Cut

Print & Cut: JV100-160 + CG-AR Series

"Mimaki Remote Access (MRA)" enables to check the machine operation status and operate the panel from a distance

It is now possible to check the status of the cutting plotter remotely from your iPhone or PC. This function enables operators to check the operation status of the machine and to operate the panel from a distance, allowing them to work more efficiently.
Mimaki Remote Access

"Mimaki Remote Access (MRA)" enables to check the machine operation status and operate the panel from a distance

Various convenient functions

Over cutting and corner cutting

Over cutting and corner cutting of starting & ending points and other corners are possible, which prevents incomplete cutting.

Over cutting and corner cutting

Continuous Crop Mark Detection

Crop marks are automatically and continuously detected. Printed graphics are accurately contour cut due to the compensation for image distortion. The detection of a maximum of 4 crop marks provides a precision finish.
Nested data which are continuously arranged in the directions of X-axis and Y-axis are cut by automatically making corrections.

Segment Compensation

Intermediate crop marks of the feed direction are detected, enabling four-point corrections for each segment. This leads to accurate, long-length cutting, even if the image is distorted.

Picture: Intermediate crop marks can be made by FineCut.

Intermediate crop marks can be made by FinCut.

Other functions and improvements

  • Division Cut Function: Cut is performed by splitting a space larger than the sheet width or splitting long data in the X-axis (feed) direction and the Y-axis (width) direction to avoid cut position gap.
  • Ethernet Connection: Network control via integration into office LAN.
  • Improved assembly and installation: Up to 30% weight reduction for simplified assembly. The addition of rubber feet makes it easier to adjust the rattle when installing on a tabletop.
  • Improved cutter holder: The cutter blade can be changed with less operation than conventional products. (4.5 turns of the knob -> 2.5 turns)

Bundled with two exclusive software programs

Professional sign making software "FineCut/Coat9"


FineCut/Coat9 is plug-in software for Illustrator and CorelDRAW, which meet all high level cutting needs, such as the creation of contour cut data from images, or division cutting with a tiling function.
FineCut/Coat9 for Illustrator
FineCut/Coat9 for CorelDRAW

Software for POP and shop interior designs using templates "Simple POP"

Simple POP

The "Simple POP" is our original software that specializes in creating POP and in-store decorations. Such POP and in-store decorations can be designed through a simple operation using templates in the Simple POP.

CG-AR Series Catalog (698.91KB)pdf file


CG-60AR Effective cut width: 606 mm (23.8")
CG-100AR Effective cut width: 1,070 mm (42.1")
CG-130AR Effective cut width: 1,370 mm (53.9")

Application list

  • Sign & Display
  • Window Graphics
  • Cutting Sheet Sticker
  • Labels & Decals
  • Package
